Custom Moses Super-Fuse Surf Fuselage

Custom Moses Super-Fuse Surf Fuselage

Due to the overwhelmingly positive response to our 710 Superfuse, we have added an 880mm Superfuse for Wing Foiling, Sup Foiling, and Windsurf foiling. The longer length matches the larger boards responsiveness while providing more pitch stability, glide, and light wind performance. The longest fuse setting is 880mm and the shortest is 710mm, so you can still get 815mm length with the longer fuse and use it for both larger and smaller boards;635mm minimum using the 710 superfuse.

This custom Stringfellow 710mm and 880mm fuselage or “Super-Fuse” as we call it allows for maximum customization of the Moses system.  There are three separate and effective adjustments on this fuselage that make it unique and totally customize-able.  It is like having 20 different fuselages in one.

• Mast placement – The mast position can be set in the standard position or 45mm forward. This allows you to ride smaller boards, ride faster with the same stance, or simply adjust for a more balanced stance.
• Stabilizer placement – The Stabilizer can be mounted in one of three positions to adjust the distance between front wing and the rear stabilizer wing in 2.5cm increments.  This will give you adjustment over the turning radius, pitchiness, and pump cadence.
• Stabilizer angle – Changing the stabilizer angle will help you maximize the range of every wing and find the perfect performance.  The two supplied 1/2 degree shims will give you control over your foil’s pitchiness, top speed, lift curve, turn response, and glide.

Must be used with Moses Surf series wings. Some examples are 633, 683, 790, 873, 1100, 720, 679.  Front wing adapter required for kite series wings.

Package includes:

1x – Fuselage

1x – Mast pocket plug

1x – Stabilizer pedestal

2x – 1/2 deg stabilizer shim

*HW not included. Takes standard Moses HW sizes which change based on the wings being used.  Contact us for spare Hardware at a discounted price with your purchase.

Available separately:

• Kite Wing to Surf fuselage adapter
• Hardware
